If you Save or Print a file in DraftSight, you’ll be prompted to Activate the software. All of the placement options will look very familiar to most 2D users. The example I created included a gradient shaded hatch. This makes the options standout and will allow the user to identify the options available much faster.īasic Block Commands are also available. One of the unique features of this tool is the Enhanced Command Window which features colors for options as you enter geometry creation commands. Below is a screenshot that shows all the details. The layers interface is very clean and appears to have all the major tools and features necessary. One of the features I immediately noticed is that DraftSight contains a Polar snap setting, which was always missing in DWGeditor. Below is a screenshot of the default screen you see when you start the program.Īlthough I don’t use 2D tools very much at all any more, I was still able to find my way around the product since it is VERY much like AutoCAD. It also contains some enhancements which do make this product unique. The look and feel is very “modern” which is refreshing when compared to the IntelliCAD based SolidWorks 2DEditor (DWGeditor).
Installation literally takes less than a minute. The product is little over 40 megabytes when downloaded. Will offer both MAC & LINUX versions later this year.Commercial version bundles API & Tech Support sold as FlexLM license by all DS Reseller Channels.Online DraftSight Community using the new DS SWYM platform.
If you print or save, a one-time e-mail submission is required for the Free version.API Extension and Direct Technical Support can be purchased as Add-Ons.Increased performance over many 2D packages.FREE download version to anyone who wants it.Below are the highlights of what is being offered.
Draftsight 2016 gratis software#
I jumped at the chance and even got to test drive a pre-beta version of the software to see for myself what it was all about. Last week I was contacted by a PR agency and was asked if I would like to see the product first hand and review some of the details of the program.
Draftsight 2016 gratis for free#
Dassault Systemes today announced the introduction of DraftSight, a 2D CAD tool that is available for download for FREE at.
